BRAND NEW FACTORY SEALED & RETAIL BOXED WITH THE FULL CISCO WARRANTY!!!
The Cisco Catalystamp 3650 Series is the next generation of enterprise-class standalone and stackable access-layer switches that provide the foundation for full convergence between wired and wireless on a single platform. The Cisco Catalyst 3650 is built on the advanced Cisco StackWiseamp;reg;-160, and takes advantage of the new Ciscoamp;reg; Unified Access Data Plane (UADP) application-specific integrated circuit (ASIC). This switch can enable uniform wired-wireless policy enforcement, application visibility, flexibility, application optimization, and superior resiliency. The Cisco Catalyst 3650 Series Switches support full IEEE 802.3at Power over Ethernet Plus (PoE+), and offer modular and field-replaceable redundant fans and power supplies. They can help you increase wireless productivity and reduce your TCO.
Specifications
- Manufacturer :Cisco Systems
- Brand :Cisco
- Product Line :Cisco Catalyst
- Model :3650-24PD-L
- Packaged Quantity :1
- RAM
- Installed Size :4 GB, 4 GB, 4 GB, 4 GB
- Flash Memory
- Installed Size :2 GB, 2 GB, 2 GB, 2 GB
- Performance
- Performance :Switching capacity: 88 Gbps, Forwarding performance: 65.47 Mpps
- Capacity
- Capacity :IPv4 routes: 24000, Switched virtual interfaces (SVIs): 1000, Virtual interfaces (VLANs): 255
- Networking
- Type :Switch
- Subcategory :Network hubs and switches
- Subtype :Gigabit Ethernet
- Form Factor :Rack-mountable, Desktop
- Stackable :Stackable
- Ports Qty :24
- Routing Protocol :Static IP routing
- MAC Address Table Size :32000 entries
- Jumbo Frame Support :9198 bytes
- Manageable :Yes
- Remote Management Protocol :RMON 9, SSH, RMON 2, SNMP 2c, SNMP 1, RMON 3, Telnet, SNMP 3, RMON 1, CLI
- Power Over Ethernet (PoE) :PoE+
- PoE Budget :390 watt
- Status Indicators :Port duplex mode, Port transmission speed, Active, PoE, Status, System
- Ports
- Qty :24
- Type :10/100/1000 (PoE+)
- Ports (2nd)
- Qty :2
- Type :10 Gigabit SFP+
- Expansion Slots
- Expansion Slots :1 (total) / 1 (free) x Stacking Module slot
- Interface Provided
- Software
- Type :Cisco IOS LAN Base
- Power Device
- Type :Internal power supply
- Hot-Plug :Hot-plug
- Power Redundancy :Optional
- Power Redundancy Scheme :1+1 (with optional power supply)
- Installed Qty :1
- Max Supported Qty :2
- Power Provided :640 watt
- Nominal Voltage :AC 120/230 V
- Frequency Required :50/60 hertz
- Miscellaneous
- Color Category :Black
- Rack Mounting Kit :Included
- Height (Rack Units) :1
- Authentication Method :TACACS+, RADIUS, Secure Shell (SSH)
- MTBF :528,280 Hours
- Dimensions & Weight
- Width :17.5 inch
- Depth :17.6 inch
- Height :1.7 inch
- Weight :16.01 lbs
