M0S90A HPE MSA 8TB 12G SAS 7.2K LFF Hard Drive

BRAND NEW WITH FULL HPE WARRANTY!!!

Overview

The M0S90A HPE MSA 8TB 12G SAS 7.2K LFF (3.5-inch) 512e Midline Hard Drive is an enterprise storage drive designed for compatible HPE MSA storage arrays. It provides 8TB of raw capacity, a 12Gb/s SAS interface, and a rotational speed of 7,200 RPM, making it suitable for capacity-focused enterprise storage deployments.

Designed for business storage environments that require substantial disk capacity, this 3.5-inch Large Form Factor drive supports workloads such as shared file repositories, departmental data, backup storage, and centralized business information. Its 512e sector format supports compatible storage platforms that recognize this drive specification.

The M0S90A is an HPE MSA-specific drive option intended for supported storage arrays rather than a general-purpose standalone desktop drive. Before purchasing, IT teams should verify array compatibility, firmware requirements, drive-bay support, and the applicable warranty for the supplied unit.

Key Features – HPE MSA 8TB SAS Hard Drive

• Processor: Not applicable; this is a storage device.
• Memory: No system memory; drive cache details are not confirmed in the cited HPE specification.
• Storage: 8TB raw capacity.
• Controller: Requires a compatible HPE MSA SAS storage controller.
• Networking / Ports: Dual-port SAS connectivity through a compatible storage enclosure.
• Power & Cooling: Powered and cooled by the compatible storage system.
• Management: Drive monitoring and management are handled through the supported HPE MSA storage platform.
• Security: Digitally signed firmware is not confirmed for this specific SKU in the cited distributor listing.
• Form Factor: 3.5-inch Large Form Factor (LFF).
• Hot-Swap Support: Hot-plug drive for supported HPE MSA storage systems.

Technical Specifications

• Manufacturer: Hewlett Packard Enterprise (HPE).
• Manufacturer Part Number: M0S90A.
• Spare Part Number: 813866-001.
• Product Type: Enterprise hard disk drive.
• Processor Type: Not applicable.
• Chipset / Platform: Compatible HPE MSA storage platforms.
• Memory Technology: Not applicable.
• Storage Capacity: 8TB.
• Storage Interface: 12Gb/s SAS.
• Drive Technology: Mechanical hard disk drive (HDD).
• Rotational Speed: 7,200 RPM.
• Form Factor: 3.5-inch LFF.
• Sector Format: 512e.
• Drive Class: Midline (MDL).
• RAID Support: Depends on the compatible HPE MSA array and its supported RAID configuration.
• Expansion Slots: Not applicable to an individual drive.
• Networking: No independent Ethernet connection; SAS connectivity is provided through the storage system.
• I/O Ports: Dual-port SAS interface through the supported drive connector and enclosure.
• Operating System Compatibility: Depends on the host server, storage array, and supported storage configuration.
• Platform Compatibility: HPE MSA 1040 and MSA 2040 are identified in distributor compatibility information. Confirm compatibility with the exact array model and firmware before ordering.

Physical Specifications

• Form Factor: 3.5-inch Large Form Factor (LFF) hard drive.
• Weight:

  • 1.13 kg
  • 2.5 lbs
• Dimensions (W × D × H):
  • 105.8 × 170.0 × 26.8 mm
  • 4.17 × 6.69 × 1.06 inches
• Rack Compatibility: Installs in a compatible HPE MSA storage enclosure; the drive itself is not a rack-mounted unit.

Ideal For

• Expanding capacity in compatible HPE MSA storage arrays.
• Enterprise file storage and shared business repositories.
• Centralized storage for departmental applications and business documents.
• Capacity-focused backup and data-retention environments.
• Organizations maintaining supported HPE MSA 1040 or MSA 2040 platforms.
• IT infrastructure teams standardizing on HPE-qualified storage components.

Warranty & Support

• Standard Manufacturer Warranty: The HPE product documentation identifies the drive as a one-year-warranty option. Confirm the warranty applicable to the specific unit being sold.
• Support Contract Compatibility: Eligibility depends on the installed HPE MSA system, the registered drive option, and the applicable support agreement.
• Technical Support: Refer to HPE support documentation for compatibility, installation, firmware, and troubleshooting requirements.

FAQs – HPE MSA 8TB SAS Hard Drive

1. What is the storage capacity of M0S90A?
The M0S90A provides 8TB of raw storage capacity. Usable capacity depends on formatting and the storage-array configuration.

2. Which systems support this hard drive?
Distributor compatibility information identifies HPE MSA 1040 and MSA 2040 storage arrays. Verify the exact model, firmware, and supported drive options before ordering.

3. Can the drive be hot-swapped?
It is listed as a hot-plug drive for compatible HPE MSA systems. Follow the array's maintenance procedures before replacing or installing a drive.

4. Does M0S90A include a RAID controller?
No. It is an individual hard drive. RAID functionality is provided by the compatible HPE MSA storage array and its supported configuration.

5. Can I install this drive in any server with a 3.5-inch bay?
No. A matching drive size does not guarantee compatibility. The host must support the SAS interface, drive connector, firmware, and required storage configuration.

6. What are the physical weight and dimensions?
The distributor-listed weight is 2.5 lbs (approximately 1.13 kg), and the dimensions are 105.8 × 170.0 × 26.8 mm (4.17 × 6.69 × 1.06 inches). These values should be treated as distributor-sourced rather than independently verified HPE specifications.
