P09151-B21 – HPE 10TB SAS 12G Midline 7.2K LFF HDD

BRAND NEW WITH FULL HPE WARRANTY!!!

Overview

The HPE 10TB SAS 12G Midline 7.2K LFF (3.5-inch) Standard Carrier HDD (P09151-B21) is an enterprise hard drive designed to expand storage capacity in compatible HPE server environments. With 10TB of capacity, a 7,200 RPM rotational speed, and a 12Gb/s SAS interface, this drive supports high-capacity storage requirements across business file services, backup repositories, data retention, and bulk-storage applications.

Featuring helium-filled construction, 512e sector formatting, and digitally signed firmware, the P09151-B21 is built for enterprise storage deployments that prioritize capacity and compatibility with supported HPE platforms. Its 3.5-inch Large Form Factor (LFF) and standard carrier design support installation in compatible server drive bays. Businesses should verify server generation, SAS controller compatibility, and supported drive configurations before ordering.

Key Features – HPE P09151-B21

• Processor: Not applicable; this is a hard disk drive.
• Memory: Not applicable.
• Storage: 10TB HDD capacity.
• Controller: Requires a compatible SAS storage controller.
• Networking / Ports: SAS 12Gb/s drive interface.
• Power & Cooling: 5.0W idle; 5.8W random read/write; 7.3W sequential read; 5.7W sequential write.
• Management: Managed through compatible HPE server and storage-controller tools.
• Security: Digitally signed firmware.
• Form Factor: 3.5-inch Large Form Factor (LFF), standard carrier.
• Rotational Speed: 7,200 RPM.
• Sector Format: 512e.
• Drive Construction: Helium-filled.
• Warranty: One-year limited warranty.

Technical Specifications

• Manufacturer: Hewlett Packard Enterprise (HPE).
• Manufacturer Part Number: P09151-B21.
• Product Type: Midline enterprise hard disk drive.
• Storage Capacity: 10TB.
• Processor Type: Not applicable.
• Chipset / Platform: Host-server and controller dependent.
• Memory Technology: Not applicable.
• Storage Interface: SAS 12Gb/s.
• Maximum Interface Transfer Rate: 12Gb/s theoretical interface rate.
• RAID Support: Depends on the compatible server storage controller and supported RAID configuration.
• Expansion Slots: Not applicable; requires a compatible 3.5-inch LFF drive bay.
• Networking: Not applicable.
• I/O Ports: SAS drive interface.
• Bytes per Sector: 512 bytes.
• Sector Format: 512e.
• Firmware Security: Digitally signed firmware.
• Drive Technology: Helium-filled HDD.
• Operating System Compatibility: Depends on the host server, storage controller, and operating system.
• Carrier Type: Standard Carrier (ST).
• Supported Environment: Compatible HPE servers and storage platforms supporting this drive option.

Physical Specifications

• Form Factor: 3.5-inch Large Form Factor (LFF), standard carrier.
• Weight:
  • 1.36kgs.
  • 3.00lbs.
• Dimensions (H × W × D):
• • 26.4 × 110.7 × 188.7 mm.
  • 1.04 × 4.36 × 7.43 inches.
• Rack Compatibility: No direct rack mounting; installs in a compatible server drive bay.

Ideal For

• Enterprise Backup Systems: Expand storage capacity for backup and recovery data.
• Business File Servers: Store large volumes of shared files and departmental documents.
• Data Retention: Maintain archived records and historical business datasets.
• HPE Server Storage Expansion: Add capacity to compatible HPE server configurations.
• Data Center Storage: Support high-capacity SAS storage workloads.

Warranty & Support

• Standard Manufacturer Warranty: One-year limited HPE warranty for this Midline hard drive.
• Support Contract Compatibility: Additional support eligibility depends on the product entitlement, host server, and applicable HPE service terms.
• Deployment Support: Confirm server compatibility, SAS controller support, firmware requirements, and available drive bays before installation.

FAQs – HPE P09151-B21

1. What is the storage capacity of the HPE P09151-B21?
The drive provides 10TB of storage capacity for compatible enterprise server deployments.

2. Is the P09151-B21 a SATA or SAS drive?
It is a SAS hard drive with a 12Gb/s interface. It is not interchangeable with SATA drives simply because they share the same physical form factor.

3. What type of carrier does this drive use?
The P09151-B21 uses a standard carrier (ST). Confirm the required carrier and drive-bay configuration for your server before purchasing.

4. Does the P09151-B21 support RAID?
RAID functionality depends on the compatible server storage controller and supported configuration. The drive itself does not provide RAID functionality.

5. Can this drive be installed in any HPE ProLiant server?
No. Compatibility depends on server generation, supported LFF drive bays, SAS controller, and firmware. Check the relevant HPE QuickSpecs before ordering.

6. What workloads are suitable for this drive?
Its 10TB capacity and 7,200 RPM speed make it suitable for high-capacity storage, backup repositories, file services, and data-retention workloads.
